The RK 1900 is a dust extraction system which was developed for the efficient and safe dedusting of large workpieces. With a 360° degree rotation of the slewing crane, workpieces up to 1000 kg can be brought into any desired position. To guarantee security, the resulting dust will be constantly fed into the filter system.
- Suitable for sand, dust, metal dust and plastic splinters up to 50μ
- Manually adjustable slewing crane enables 360° degree rotation
- Constant extraction of accuring dust
- Integrated filter system
-
Workpiece material
- Air filter - Krumm-tec
- Metal
- Metal (prototyping)
- Plastics
- SLS (prototyping)
-
Sizes
- Larger sizes than 1300 x 1100 mm
- Medium sizes 1300 x 1100 mm
-
Cleaning
-
Methods
- Solutions for Blasting dry ice and with granulates
- Solution for Extraction and filtration
-
Specifications
Workspace (WxHxD):
2000 x 1600 x 2600 mmLoad:
1000 kgDimensions (WxHxD):
2100 x 1700 x 2800 mmWork height min./max.:
0–2000 mmFeed:
Fork lift, lifting systems
Detail-/Product Pictures
no data yet...
